Description

Our electric counterbalance forklifts offer maximum efficiency with minimum energy consumption. Agile electric forklifts offer top performance with the latest three-phase motor. This technology coordinates all forklift components, improving the efficiency of your operations. Efficiency meets economy in an electric forklift.

Locally refurbished equipment is guaranteed for a period of 6 months or 500 operating hours.

The equipment has operating authorization from ISCIR and can legally be operated instantly after delivery.

Benefit now from our offer on refurbished equipment.

Additional features:

  • Forks, ISO 2A, 40 x 80 x 1150 mm. Description: 1 pair (2 forks);
  • Sideshift, hooked on, Width 980 mm, ISO 2A. Side shift +/- 100 mm, 980 mm wide, ISO 2A. With quick release coupling;
  • Load guard;
  • Auxiliary hydraulics, ZH 1, for fork carriage, 1x changeable connection. Including 3-way valve, for all masts. For 1 extra function, hose guide inside;
  • Battery holder preparation for battery exchange with SnapFit;
  • Rear-view mirror, panorama, inside right;
  • Acoustic warning buzzer when reversing. Noise level 95 dB;
  • Lighting, 2 working lights, LED, on overhead guard, front. Position S5 + S6. Function on during forward travel;
  • Lighting, beacon, LED. Flush with the overhead guard. Position P3. Function can be manually activated / deactivated, via softkey or FN level.
Manufacturer
Jungheinrich
Model
EFG 316k
Load capacity / rated load
1600 kg
Load centre distance
500 mm
Wheelbase
1400 mm
Net weight incl battery
2994 kg
Axle load with load front/rear
3995 / 599 kg
Axle load without load front / rear
1362 / 1632 kg
Tyres
Super-elastic (SE)
Tyre size, front
18 x 7-8
Tyre size, rear
16 x 6-8
Lift
3500 mm
Retracted mast height
2310 mm
Free lift
1575 mm
Extended mast height
4090 mm
Overall lenght
3144 mm
Overall width
1060 mm
Fork dimensions
40 / 80 / 1150 mm
Ground clearance centre of wheelbase
100 mm
Ground clearance laden under mast
97 mm
Aisle width (pallet 1000×1200 sideways)
3407 mm
Aisle width (pallet 800x1200 length)
3603 mm
Turning radius
1859 mm
Travel speed, laden / unladen
17 / 17 km/h
Lift speed, laden / unladen
0.51 / 0.74 m/s
Lowering speed, laden / unladen
0.55 / 0.55 m/s
Drawbar pull laden
2150 N
Max. drawbar pull laden/ unladen
13000 / 11900 N
Gradeability, laden / unladen
7.3 / 12.3 %
Max. gradeability laden / unladen
27 / 30 %
Acceleration time laden/unladen
5.7 / 5.2 s
Parking brake
electric / mechanical
Drive motor, performance S2 60 min
4.5 kW
Lift motor, performance with S3
11.5 kW
Battery voltage / nominal capacity
48V / 625Ah
Battery weight
855 kg
  • Refurbished
  • Fast Shipping

    • REFURBISHED Electric counterbalance forklift Jungheinrich EFG 316k, capacity 1600 kg, lift height 3500 mm

    • Year of manufacturing: 2017
    • Capacity: 1600 kg
    • Lift height: 3500 mm
    • Operating hours:7,154

    Lei67,726.35
    Tax excluded
    €13,090.00
    FN546441
    Status: In stock
