Description

The AMX 10 scissor lift pallet truck delivers premium Jungheinrich quality in a highly versatile package. You can use it as a hand pallet truck, lift table, provisioning table or workbench. With just a few pumps of the tiller, you can raise loads weighing up to 1000 kg to a comfortable, fatigue-free working height. As of a lift height of 400 mm, support feet provide additional stability and security for the scissor lift pallet truck.

  • Flexible application, can also be used as a lift table or workbench
  • Automatic quick lift up to 120 kg
  • 800 mm lift height for ergonomic working
  • Ergonomic tiller handle that can be operated with either hand
  • Available with optional lateral support rollers
  • Also available with electric lift

Just a few tiller strokes raise the load to a comfortable, ergonomic height

The AMX 10 scissor lift pallet truck is a premium Jungheinrich product offering durable and reliable quality. As a combination between a pallet truck and lift table, the scissor lift pallet truck is extremely flexible and versatile.

Activities involving frequent bending and heavy lifting can quickly have an effect on employee health. Supported by the automatic quick lift up to 120 kg, loads weighing up to 1000 kg can be raised to an optimum ergonomic height with just a few pumps of the tiller. The truck thus serves as an invaluable aid when working with pallets or pallet cages. It goes without saying that you can also use the AMX 10 as a hand pallet truck to transport your goods.

The lift/travel/lower functions are controlled via the ergonomic tiller handle, which can be easily operated with either hand. Thanks to the special lowering valve, loads can be set down with utmost control and precision. You can adjust the working height of the AMX 10 up to a height of 800 mm. As of a lift height of around 400 mm, side-mounted support feet provide additional stability. They secure the pallet truck, which can then no longer move and thus serves as a useful work table. You also have the option of equipping the scissor lift pallet truck with lateral support rollers so that you can also move it when raised.

The fork arms with their closed fork tips and welded construction are torsion-free and highly durable. As a result, the scissor lift pallet truck retains its shape even under the heaviest loads. The single-stage lift cylinder makes the AMX 10 particularly resilient and minimises the risk of leaks. The overload valve protects against excess loads.

Depending on the ground conditions and specific application, you can choose between a range of wheel and roller materials. Order the versatile Jungheinrich scissor lift pallet truck from our shop in your chosen configuration.

Manufacturer
Jungheinrich
Model
AMX 10
Drive mode
Pedestrian
Operation mode
Manual
Load capacity / rated load
1000 kg
Load centre distance
600 mm
Load distance
1030 mm
Wheelbase
1383 mm
Axle load with load front/rear
406 / 751 kg
Axle load without load front / rear
101 / 56 kg
Service weight
157 kg
Tyres
Polyurethane
Load wheels type
Single
Number of front / rear wheels
2 / 2
Steering / drive tyres size
Ø 170 x 50
Load tyres size
82 x 62 mm
Steering / drive wheel material
Nylon
Load wheels material
Polyurethane / Nylon
Tread width, front
109 mm
Tread width, rear
440 mm
Lift
800 mm
Lifting range
86 - 800 mm
Height of tiller in drive position min / max
1299 mm
Overall lenght
1650 mm
Overall width
560 mm
Fork dimensions
53 / 150 / 1150 mm
Width across forks
560 mm
Ground clearance centre of wheelbase
30 mm
Aisle width (pallet 800x1200 length)
2005 mm
Turning radius
1635 mm
Lowering speed, laden / unladen
0.11 / 0.04 m/s
Lift truck material
steel
Grease nipple
yes

Scissor lift pallet truck Jungheinrich AMX 10, capacity 1000 kg

Manually raises loads to an ergonomic working height

  • Flexible application, can also be used as a lift table or workbench
  • Automatic quick lift up to 120 kg
  • 800 mm lift height for ergonomic working

Lei7,147.71
Tax excluded
€1,420.00
50441572
Status: Out of stock
